Features

• Energy Saving due to high efficiency and superior transformer design.
• Extremely high efficiency by use of-Prime Grade CRGO lamination and high purity Electrolytic Copper Wires/Strips used.
• Machine wound varies with special Carbon brushes for enhanced life.
• High speed of Correction up to 35V/ Sec for three Phase and 20V/Sec for single Phase.
• Isolated Servo drive without Relays. Hence No noise Generated.

  Specification-Capacity :	380V/400V/415V/Three Phase (Adjustable)
  1KVA to 20 KVA (Single Phase)	Frequency : 47 Hz-53Hz.
  2KVA to 250 KVA (Three Phase)	Efficiency : Better Than 97%
  Input Voltage Range:	Regulation : ±1% or Better.
  180/160V/140V-270V (Single Phase)	Over Load Capacity : Up to 200% Momentarily
  315V/275V/260V-470V(Three Phase)	No Load Losses : Less than 0.8% Over entire range.
  Output Voltage Range:	Rate of Correction : Better than 36VSec. in
  220V/230V/240V Single Phase (Adjutable)	Air cooled Better than 20V/Sec. in Oil Cooled.
